Product Description:

Commutator series motor is a original parts which could keep the motor of DC permanent magnet moving on . it is a multitude of copper elements insulated (spaced) among each other and reinforced with insulation compound .Each individual copper element is a bar joined on one end via connection in form of hook or groove with the end of the armature winding coil. Electric current is transferred to commutator through two slip carbon contacts – brushes exerting pressure onto the commutator surface (brush track) by force of a spring.

Technology
Application of the state-of-art development tools
Proper construction and production of tools and machines
Analyses as to potential improvements in commutator mounting
Automation and visual inspection

Technical Information

Production procedure:
1. Putting piston into cylinder body
2. installing spring , screw , thrust piece , O-ring
3. installing front cover
4. Installing shaft sealing , running-in
5. Testing gap , then installing cylinder head
6. Adding PAG46 , leak-checking , washing
7. Installing clutch
8. Packing

Technical Information

5V new series solenoid valve

1. Features
● Single solenoid valve uses new design with piston reset and improve steadiness, functionality and life time.
● We guarantee inner hole with Ra0.1 roughness within our new processing.
● Special treatment to take care of inner hole to reduce the resistance, for the spool adding anti-friction seal to improve the stability during movement.
● For our manufacturing process we use imported HNBR to reduce friction.
● To import German high standard special grease which provides film in order to reduce the friction.
● To introduce Taiwan high precise injection mould and seals die, to enhance precision and stability.
● New visual style, synchronized with global outstanding product standard.
● Adding the logo on behalf of the company innovation for individual market recognition on the product which has design patent.

2. Specification

3. Application Solenoid valve is used to control industrial equipment, to control the automation of fluid components. It used in industrial control system to adjust the direction of the media, flow, speed and other parameters, which belongs to the actuator, not limited to hydraulic or pneumatic. Through the coordination of different circuits to achieve the desired control, and to ensure the accuracy and flexibility of control.

4V Economic solenoid valve

1. Features
● 5 ports solenoid valve 4V100, 200, 300, 400 series.
● Internally piloted action, 5 port 2 position or 5 port 3 position.
● Body: Black anodization, hand anodization, natural anodization.
● Small flow resistance,reveersing sensitive,change the direction sensitive.
● Long useful life,strong memory function.
● Used as control element in the pneumatic system.
● Computer numerical control(CNC) machined.

2. Specification

3. Application Solenoid valve is used to control industrial equipment, to control the automation of fluid components. It used in industrial control system to adjust the direction of the media, flow, speed and other parameters, which belongs to the actuator, not limited to hydraulic or pneumatic. Through the coordination of different circuits to achieve the desired control, and to ensure the accuracy and flexibility of control.

Introduction

Using native tungsten carbide and imported production equipment from Germany, the fully automatic precision press forming technology keeps the product density distribution more uniform. Otherwise the product will has holes during the sintering process, causing collapse knife or fragments. The over pressure sintering furnace for sintering make products better compactness.

Packaging

Introduction

Mainly used for drilling, production testing, perforation, in the course of testing oil seal cables. It uses circular gate, the

situation of the godd, simple structure, bothe manual and hydraulic switching, a single-gate structure, Newcore board, the three gate, a manual and a total of five kinds of liquid; connections to the production from top to bottom the previous structure, and can be converted well head flange or other BOP link.

Mainly used for drilling test window, oil wells, repair, minor repairs, test oil operations, it uses a long circular gate, force, compact structure is divided into: manual and hydraulic ip and down to connect into the form: double flange, planted on the wire under the flange, the Xiazai wire-type three, Can be arbitrarily selected according to the needs of users, Full range: To meet the drilling , underbalanced drilling, underground work, with the pressure snubbing operations and other purposes. Series full specifications, size from 7 1/16 in a 13 5/18 in, pressure level 5000psi a 15000psi. Versatile: With a full-closed gate, half-closed gate, shear ram, can be used for special purpose.
